*Special order only (4-6 week lead time).


TECHNICAL INFORMATION

SPECIFICATIONS



Flooring type Heavy compact vinyl
Heterogeneous PVC Glue down
Usage class 23 - 33 - 42
Total thickness 2.00 mm
Wear layer 20mil (0.50 mm)
Wear layer treatment HyperGuard+
Width 13'2" (4 m)
Standard length 82' (25 m)
Standard roll size 1,076 ft2  (100 m2)
Weight 0.44 lbs/ft2 (2.15 kg/m2)
Weight of standard roll 475 lbs (216 kg)
Warranty Lifetime Residential & 15 Year Commercial



PERFORMANCE



Inflammability EN 13501-1 Bfl-S11
Slip Resistance EN 13893 DS
Slip restraint EN 16165 Annex B R10
Residual indentation EN ISO 24343-1 norm ≤ 0.10 mm
Furniture leg resistance EN ISO 16581 PASS
Curling EN ISO 23999 ≤ 8 mm
Electrical resistance EN 1081 3.99 x 108 Ohm
Static electrical propensity EN 1815 ≤ 2kV (antistatic)
Dimensional stability EN ISO 23999 norm ≤ 0.40%
Thermal conductivity ISO 8302 (1991) 0.130 W/(m.K)
Heat insulation EN 12667:2001-01 0.0153 (m².K/W)
Binder quantity in wear layer EN 10582 Type I
Abrasion group EN 660-2 Class T
Indoor air quality LOW VOC
Acoustic insulation EN ISO 717-2 ΔLw 8 dB
Castor chair resistance EN ISO 4918 Pass
Castor type EN 12529 Type W
Light fastness ISO 105-B02 ≥ 6
Underfloor heating EN 12524/EN 12667 Suitable ≤ 27°C
Resistance to chemicals EN ISO 26987 Very good
Hot welding Available
Cold welding Invisiweld Suitable
Commercial warranty2 15 years

1Tested on concrete subfloor (Cfl-S1 on wood).

2The warranty covers manufacturing defects and premature wear in the event of normal use. The products do not contain any substances from the current candidate list published by ECHA (substances of very high concern) to be published under the REACH regulation. Exclude any rubber parts that may come into direct contact with the flooring (chair ends, furniture, wheels). Use only PVC or polyethylene components. IVC reserves the right to change or amend any written information without notice. Ensure the latest information is being consulted by referring to the website.










Accessories

Adhesive

Certified for Shamrock Surfaces Luxury Vinyl flooring, UNiSTiK ULTRANSiTiONAL is a pressure-sensitive, high-shear adhesive that seamlessly transitions between both properties. This aggressive, high-tack, universal adhesive is engineered for resilient and modular flooring installations.
