TECHNICAL INFORMATION

SPECIFICATIONS



Flooring type Luxury Textile Vinyl
Type of installation Loose lay1 or glue down
Usage class 23 - 32
Total thickness 2.80 mm
Wear layer 16mil (0.40 mm)
Wear layer treatment PU lacquer
Width 13'2" (4 m)
Standard length 98'5" (30 m)
Standard roll size 1,291 ft2  (120 m2)
Weight 0.40 lbs/ft2 (1.95 kg/m2)
Weight of standard roll 516 lbs (216 kg)
Residential warranty2 Lifetime Residential & 15 Year Commercial

1Can be semi loose lay installed up to 450 ft2.

2The warranty covers manufacturing defects and premature wear in the event of normal use.

PERFORMANCE



Inflammability EN 13501-1 Cfl-S11
Slip Resistance EN 13893 DS
Slip restraint EN 16165 Annex B R10
Thermal conductivity ISO 8302 (1991) 0.0667 W/(m.K)
Heat insulation EN 12667:2001-01 0.0338 (m².K/W)
Indoor air quality REACH certified2
Acoustic insulation EN ISO 717-2 ΔLw 17 dB
Castor chair resistance EN ISO 4918 Pass
Castor type EN 12529 Type W
Light fastness ISO 105-B02 ≥ 6
Underfloor heating EN 12524/EN 12667 Suitable ≤ 27°C
Resistance to chemicals EN ISO 26987 Very good
Cold welding Invisiweld Suitable

1Tested on concrete subfloor (Cfl-S1 on wood).

2The products do not contain any substances from the current candidate list published by ECHA (substances of very high concern) to be published under the REACH regulation. Exclude any rubber parts that may come into direct contact with the flooring (chair ends, furniture, wheels). Use only PVC or polyethylene components. IVC reserves the right to change or amend any written information without notice. Ensure the latest information is being consulted by referring to the website.







Accessories

Adhesive
Invisiweld

Certified for IVC Commercial Heavy Compact, and Compact Vinyl flooring.

UNiSTiK ULTRANSiTiONAL is a pressure-sensitive, high-shear adhesive that seamlessly transitions between both properties. This aggressive, high-tack, universal adhesive is engineered for resilient and modular flooring installations.

invisiweld

Permanent. Invisible. Easy to use.

Invisiweld is the better way to install IVC Heterogeneous Vinyl, leaving a strong, seamless and watertight joint.
